Gared Performance Sports Systems Three-Point Wall Mount Mounting Kit For Rectangular Board 3'-4' Extension Length (GPS-2350-3044)

Product Features

• Telescopic 3'-4' Extension Features a modular, sliding frame that allows installers to set the exact distance from the wall to the backboard within a 36 to 48-inch range.
• Gloss Black Powder Coat Finished with a high-quality, baked-on powder coating that protects against rust, chipping, and heavy gym use.
• Versatile Board Compatibility Optimized for standard rectangular backboards (63" x 36" mounting centers) or fan-shaped boards (35" centers).
• Height Adjuster Compatible Pre-engineered to work with optional manual or electric height adjusters, allowing the rim to move from 8' to 10'.
• Maintenance-Free Construction Once installed and leveled, the solid-state steel frame requires virtually no maintenance or adjustments.
• Field-Adjustable Ease The telescopic design makes it simple for installation crews to navigate around wall obstructions like conduits or HVAC ducts.
• Professional Aesthetic Provides a clean, "college-level" look to any high school, community center, or church gymnasium.
• Direct Goal Attachment The rim bolts through the backboard directly into the heavy-duty steel frame, significantly reducing stress on the backboard during dunks.
• Three-Point Stability System Uses a triangulated steel support structure that provides exceptional rigidity and minimizes vibration after a shot or dunk.
• Heavy-Duty 4/0 Safety Chains Includes high-tensile strength safety chains and malleable turnbuckles for critical overhead support and precise leveling.
• Structural Wood Mounting Pads Comes with 2" x 8" Southern Yellow Pine clear-coated wood pads to provide a secure and professional base against the facility wall.
• Industrial Steel Tubing The main support is constructed from 2-3/4" O.D. steel tubing telescoped inside a 3" O.D. tube for massive load-bearing capacity.
• Unitized Tension Straps The entire backstop is unitized with 0.25" to 1" tension straps to ensure the unit remains perfectly plumb and rigid during intense games.
• Competition-Grade Performance Designed to meet NCAA and NFHS requirements for backboard support, being positioned at least 6" behind the board.
• Stationary Non-Folding Design A permanent, "dead-mount" solution ideal for courts where the basketball goal does not need to be folded away for other activities.
