Gared Performance Sports Systems Three-Point Wall Mount Mounting Kit For Rectangular Board 9'-12' Extension Length (GPS-2350-9124)

Product Features

• Extreme 9'-12' Telescopic Range Features Gared's longest standard telescopic extension, allowing the backboard to be positioned up to 144 inches from the wall.
• Professional Black Powder Coat Finished with a durable, baked-on powder coating that resists scratches, corrosion, and the moisture of a busy gym.
• NCAA & NFHS Compliant Engineered to meet the strict requirements for backboard support distance (frame must be at least 6" behind the board) for official play.
• Height Adjuster Compatible The frame is pre-drilled to accept optional manual or electric height adjusters, allowing the rim to be set anywhere from 8 to 10 feet.
• Stationary Non-Folding Design A permanent, "dead-mount" setup that provides maximum rigidity without the maintenance needs of folding systems.
• Field-Adjustable Ease Despite its size, the modular telescopic design allows installers to navigate around wall obstructions like HVAC vents or plumbing.
• 5-Year Structural Warranty Backed by Gared’s institutional guarantee, providing long-term security for one of the largest wall-mount units on the market.
• Direct-Goal Attachment System The rim is bolted through the backboard and directly into the steel mast, protecting the backboard from the stress of heavy dunks and hanging.
• Superior Three-Point Stability The triangulated steel frame provides the strongest stationary mounting configuration available for budget-conscious institutional projects.
• Maximum Player Safety Zone The deep 12-foot extension provides an elite-level safety buffer behind the baseline, ideal for high-speed fast breaks and competitive play.
• Heavy-Duty 5/0 Safety Chains Upgraded from standard chains, these 5/0 high-tensile safety chains provide critical overhead suspension for the massive steel extension.
• Malleable Turnbuckles Includes industrial-grade turnbuckles to allow for precise leveling and plumb adjustment of the heavy backboard at long distances.
• Institutional Structural Steel Built with heavy-walled 2-3/4" O.D. and 3" O.D. steel tubing to manage the high torque and leverage of the 12-foot reach.
• Structural Wood Mounting Pads Comes with 2" x 8" clear-coated Southern Yellow Pine pads to distribute the unit's weight and impact loads across the wall surface.
• Unitized Tension Straps Reinforced with 1/4" x 1" steel tension straps along the extension arms to ensure the unit remains rigid and prevents sway during play.
